Flare

Flare See Through Modern Linear Fireplace w/ 24" High Glass

SKU:DVST30H

$8,815.00 USD

Call 1-877-WE-LIKE-FIRE or use the contact form above for a personalized quote on this item and get our best sale pricing!

Size 30 45 50 60 70 80 100

Quantity

Up to 65,000 BTU, natural gas or propane
Two different ceramic glass heights, 16″ or 24″, for better flame view
Indoor & outdoor options
Double glass or protective screens, heat barrier
Available in 8 different sizes 25”-100” long
New multi color LED option
Electronic ignition with battery backup
“Cold Wall” above fireplace, perfect for mounting a TV
Optional Power Vent system
Includes 7 different media options: Fireglass, Ceramic Pebbles or Wood logs
Optional ceramic reflective back
Touch Remote - Six button stylish remote with timer, sleep mode, flame height adjustment, programming and temperature control.
3D Stainless Steel Burners - Longer, 3D stainless steel, burners (V.S a pipe burner) with deeper taller flame that extends closer to the sides of the fireplace
All units are certified and approved by CSA to be installed in North America, including in the states of California & Massachusetts

3D Stainless Steel Burners

Multi Color LED Lighting Option

Double Glass

Touch Remote


Fireglass - Reflective Bronze

Fireglass - Reflective Copper

Fireglass - Reflective Platinum

Ceramic Pebbles - Black

Cermaic Pebbles - White

Ceramic Pebbles - Mixed Size Earth Pebbles

Ceramic Logs

CA Residents: See Prop 65 WARNING.

MODEL SIZES

MODEL NAME	A	B	C	H	E
Flare-ST-100	101 8/16"	97 3/16"	16"	28"	5"x8"
Flare-ST-80	84 9/16"	80 1/16"	16"	28"	5"x8"
Flare-ST-70	71 15/16"	67 8/16"	16"	28"	5"x8"
Flare-ST-60	62 2/16"	57 13/16"	16"	28"	5"x8"
Flare-ST-50	52 5/16"	48"	16"	28"	5"x8"
Flare-ST-45	45 9/16"	41 5/16"	16"	28"	4"x6"
Flare-ST-30	32 10/16"	28 5/16"	24"	35 14/16"	4"x6"
Flare-ST-25	24 12/16"	20 7/16"	24"	35 14/16"	4"x6"
Flare-ST-100-H	101 8/16"	97 3/16"	24"	35 14/16"	5"x8"
Flare-ST-80-H	84 9/16"	80 1/16"	24"	35 14/16"	5"x8"
Flare-ST-70-H	71 15/16"	67 8/16"	24"	35 14/16"	5"x8"
Flare-ST-60-H	62 2/16"	57 13/16"	24"	35 14/16"	5"x8"
Flare-ST-50-H	52 5/16"	48"	24"	35 14/16"	5"x8"
Flare-ST-45-H	45 9/16"	41 5/16"	24"	35 14/16"	4"x6"

NG

Model Name	Burner Type	BTU/H Max	Input Max[KW]	BTU/H Min	Efficiency
Flare-100	H	65813	19.3	32500	80.3%
Flare-80	G	57629	16.9	31000	79.7%
Flare-70	F	55583	16.3	28000	79.8%
Flare-60	E	52173	15.3	28000	79.2%
Flare-50	D	46035	13.5	22750	79.3%
Flare-45	C	42966	12.6	22000	79.2%
Flare-30	B	34782	10.2	18500	79.5%
Flare-25	A	30690	9	17500	79.1%
Flare-100-H	H	65813	19.3	32500	80.2%
Flare-80-H	G	57629	16.9	31000	79.8%
Flare-70-H	F	55583	16.3	28000	79.8%
Flare-60-H	E	52173	15.3	28000	79.5%
Flare-50-H	D	46035	13.5	22750	79.4%
Flare-45-H	C	42966	12.6	22000	79.7%

Model Name	Burner Type	BTU/h max	BTU max [KW]	BTU min	Efficiency
Flare-100	H	51150	15	25500	76
Flare-80	G	46376	13.6	20750	75
Flare-70	F	42966	12.6	20000	79
Flare-60	E	42966	12	20000	80
Flare-50	D	40920	10.3	18500	82
Flare-45	C	26257	7700	17750	82
Flare-30	B	26257	7700	1600	81
Flare-25	A	24893	7300	12500	77
Flare-100-H	H	51150	15	25500	78
Flare-80-H	G	46376	13.6	20750	80
Flare-70-H	F	42966	12.6	20000	79
Flare-60-H	E	42966	12	20000	80
Flare-50-H	D	40920	10.3	18500	82
Flare-45-H	C	35123	7700	17750	83

Refer to the product manual for full warranty details.
