Monessen 36" Exacta Vent Free Circulating Firebox with Radiant Face
Monessen 36" Exacta Vent Free Circulating Firebox with Radiant Face
SKU:BUF36-R
Couldn't load pickup availability
EXACTA VENT FREE FIREBOX
Enjoy the fireplace you’ve always wanted, expansive views and all. Combined with a Monessen vent free log set, the Exacta firebox provides warmth and ambiance to practically anyone, anywhere. The Exacta delivers maximum airflow, efficiently adding heat to your home, while the zero clearance design gives you flexibility, and helps save installation dollars.
A Monessen vent free firebox is the perfect way to display and operate your Monessen vent free log set. While our log sets can be utilized in an existing approved wood burning fireplace (converted with a gas line), if your home does not already have an existing fireplace, a vent free firebox is an economical way to add a fireplace to your home. Installed in either your wall or a free-standing cabinet, a vent free firebox is simply the metal combustion chamber of a traditional fireplace system, without the log set and engine. You then add the vent free log set (with engine) of your choice to complete it.
Monessen offers one of the most diverse lineups of vent free gas fireboxes available, making it easy to find the right look for your home. Enjoy beautiful flames, excellent heating and a customized look with the addition of your choice of Monessen log sets.
Because vent free fireboxes and log sets are designed to be installed and operated without a chimney, flue or vent, they can be installed in locations in your home where it would be impossible or cost prohibitive to install a vented fireplace. They provide the most economical installation, only requiring a connection to a gas line.
Monessen vent free fireboxes allow for zero clearance installation, which means they may be installed flush against any combustible surface such as drywall or wood. This gives you added flexibility and helps save installation dollars when deciding where to install your fireplace, whether on an interior or exterior wall. (It is important to remember that the appliance should be sized to fit the area in which it is to be installed and must meet any additional regional or local requirements.
Monessen offers a large selection of vent free log sets (sold separately) that are a perfect complement to your new fireplace.
Exacta vent free circulating firebox are available in 36" and 42" sizes with refractory interior.
FEATURES
- No chimney or venting required makes installation fast, easy, and affordable
- Clean, louver less design
- Tuck the screen into hideaway pockets to reveal expansive views
- Black interior provides elegant background for vent free log set
- Brick interior available for a traditional look
- Large hearth area allows for a variety of log sets
- Angled firebox and uniquely engineered air channels move more heat into the room, maximizing efficiency
- CSA design certified to ANSI Z221.91.A2002
*Please Note: This is for the firebox only, no logs are included with this listing.
*Also Note: Max BTU will be determined by the log set.
*Also Note: This item is a vent free appliance and installation of it may be prohibited in your jurisdiction. Customers are responsible for checking local codes and regulations prior to purchase.
PRODUCT SPECIFICATIONS
| Exacta BUF 36 | BUF36/BUF36-R |
|---|---|
| Size: | 36" |
| Appliance Width: | 42" |
| Appliance Height: | 37-1/4" |
| Appliance Depth1: | 23" |
| Hearth Front Width: | 35-1/4" |
| Hearth Front Height: | 21-3/4" |
| Hearth Depth: | 18-5/8" |
| Hearth Rear Width: | 27-1/4" |
| Hearth Rear Height: | 20-3/8" |
| Viewing Area: | 36 x 24" |
VENTING SPECIFICATIONS
- Vent free units do not require any venting products
PRODUCT DIMENSTIONS
- Overall dimensions - 42" W (front) x 37 1/4" H x 23" D x 28 1/4" W (rear)
- Rough framing dimensions - 42 1/2" W x 37 1/2" H x 23 1/4" D
- Minimum hearth dimensions - 33 3/4" W (front) x 21 3/4" H x 17 7/8" D x 25 3/4" W (rear)
- Weight - 155 lbs.
SHOWN WITH
- Refractory firebrick liner (standard with BUF42-R)
- 30" log set (optional)
- 30" Burner (optional)
- Custom installation and surround
CA Residents: See Prop 65 WARNING
CORNER INSTALLATION
FRONT VIEW
MINIMUM HEARTH DIMENSIONS
SIDE VIEW
TOP VIEW
OPTIONS & ACCESSORIES
Burners (Required to Complete)
Click to see Burners
 | EYF18PM/EYF18NM/EYF18PV/EYF18NV Monessen popular EYF burner raise for dancing flames. Enjoy dancing, realistic flames with the EYF burner. The available EYF burner produces a fine yellow flame, heavy duty grate assembly adds an authentic touch. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
| EYF24PM/EYF24NM/EYF24PV/EYF24NV Monessen popular EYF burner raise for dancing flames. Enjoy dancing, realistic flames with the EYF burner. The available EYF burner produces a fine yellow flame, heavy duty grate assembly adds an authentic touch. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
 | GG18NV/GG18PV Glow Getter burner are available in 18" and 24" sizes, these burners feature a cast iron grate, volcanic rock, rock wool, on/off switch, manual variable flame height control and are remote ready. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
| GG18NIF/GG18PIF Glow Getter burner are available in 18" and 24" sizes, these burners formats. Featuring the IntelliFire Plus with ODS system for five-step flame adjustment, these burners come complete with cast iron grate, volcanic rock, rock wool, on/off switch, touch button command center, electronic ignition and RC300 thermostat remote control. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
| GG24NV/GG24PV Glow Getter burner are available in 18" and 24" sizes, these burners feature a cast iron grate, volcanic rock, rock wool, on/off switch, manual variable flame height control and are remote ready. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
| GG24NIF/GG24PIF Glow Getter burner are available in 18" and 24" sizes, these burners formats. Featuring the IntelliFire Plus with ODS system for five-step flame adjustment, these burners come complete with cast iron grate, volcanic rock, rock wool, on/off switch, touch button command center, electronic ignition and RC300 thermostat remote control. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
 | NB18NV/NB18PV Natural Blaze burner available in 18" and 24" sizes, these burners come in both natural and propane gas formats and feature a cast iron grate, volcanic rock, rock wool, on/off switch, manual variable flame height control and are remote ready. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
| NB18NIF/NB18PIF Natural Blaze burner available in 18" and 24" sizes, these burners come in both natural and propane gas. Featuring the IntelliFire Plus with ODS system for five-step flame adjustment, these burners come complete with cast iron grate, volcanic rock, rock wool, on/off switch, touch button command center, electronic ignition and RC300 thermostat remote control. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
| NB24NV/NB24PV Natural Blaze burner available in 18" and 24" sizes, these burners come in both natural and propane gas formats and feature a cast iron grate, volcanic rock, rock wool, on/off switch, manual variable flame height control and are remote ready. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
| NB24NIF/NB24PIF Natural Blaze burner available in 18" and 24" sizes, these burners come in both natural and propane gas. Featuring the IntelliFire Plus with ODS system for five-step flame adjustment, these burners come complete with cast iron grate, volcanic rock, rock wool, on/off switch, touch button command center, electronic ignition and RC300 thermostat remote control. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
 | PH18PM/PH18NM/PH18PV/PH18NV Monessen popular PH burner raise for dancing flames. Enjoy dancing, realistic flames with the PH burner. The available PH burner produces a fine yellow flame, and the cast iron grating adds a decorative touch. These log sets feature burners with flames in the front and rear, adding warmth and ambience to any room. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
| PH24PM/PH24NM/PH24PV/PH24NV PH burner are available in 18" and 24" sizes, these burners feature manual control and come in both Natural Gas and Propane. Also available in remote-control ready burners come in both Natural Gas and Propane. Millivolt Control Valve comes with On/Off Switch and Manual Variable Flame Height Control. FEATURES
* Please Note: This is for the gas burner only. No logs are included. |
Logs (Required to Complete)
Click to see Logs
 | EYF18-R
|
 | EYF24-F
|
 | EYF24-R
|
 | CR18-H
|
 | DY18-H
|
 | MX18-H
|
 | CR24-H
|
| DY24-H
|
| MX24-H
|
 | BC18-R
|
 | BO18-F
|
 | BO18-R
|
 | HO18-R
|
 | SC18-R
|
| BC24-R
|
| BO24-F
|
| BO24-R
|
| HO24-R
|
| SC24-R
|
 | PH18R
|
| PH24R
|
Log Accessories
Click to see Optional Log Accessories
 | SC18EK The Monessen 18" Stony Creek Vent Free Gas Log Set features the choice to add the two top log enhancement kit. This enhancement kit is priced reasonably and adds two additional logs to the very top of the stack to make a fuller look that goes well with larger fireplaces. Each log has been made with the utmost take care of a realistic, authentic look that you simply won't find anywhere else.
|
| SC2430EK The Monessen 24" & 30" Stony Creek Vent Free Gas Log Set features the choice to add the two top log enhancement kit. This enhancement kit is priced reasonably and adds two additional logs to the very top of the stack to make a fuller look that goes well with larger fireplaces. Each log has been made with the utmost take care of a realistic, authentic look that you simply won't find anywhere else.
|
Mantels
Click to see Optional Mantels
 | B KENWOOD FLUSH MANTEL (AFKDMPB/AFKDAUB)
B SIZE TECHNICAL SPECIFICATIONS (A) - Opening Width - 48" * Please Note: This is the Mantel only. |
 | B KENWOOD 60" OUTSIDE WIDTH FLUSH MANTEL (AFKDMPB60)
B60 SIZE TECHNICAL SPECIFICATIONS (A) - Opening Width - 46" * Please Note: This is the Mantel only. |
 | B WESCOTT FLUSH WOOD MANTEL (AFWTMPB)
B SIZE TECHNICAL SPECIFICATIONS (A) - Opening Width - 48" * Please Note: This is the Mantel only. |
 | B RICHLAND FLUSH WOOD MANTEL (AFRDMPB)
B SIZE TECHNICAL SPECIFICATIONS (A) - Opening Width - 48" * Please Note: This is the Mantel only. |
 | B ROXBOROUGH FLUSH WOOD MANTEL (AFRHMPB/AFRHAUB)
B SIZE TECHNICAL SPECIFICATIONS (A) - Opening Width - 48" * Please Note: This is the Mantel only. |
Mantel Base
Click to see Optional Mantel Base
 | B KENWOOD FLUSH MANTEL BASE (HTKDMPB/HTKDAUB) Flush wood mantels and base are a great value that create a focal point for all rooms. Each is delivered ready to finish with your choice of paint or stain to perfectly match the personal style and décor of your home.
B TECHNICAL SPECIFICATIONS (A) - Top Width - 69-1/2" |
Accessories
Click to see Optional Brick Panels
 | FBBUF36R
*Note: Refractory firebrick (sides and back panels) for BUF36. (Not needed for BUF36-R.) |
Click to see Optional Air Blower
 | BLOTMC
Compatible with the following Monessen appliances
|
Click to see Optional Outside Air Kit
 | AK22
Compatible with the following Monessen appliances
|
Click to see Optional Flex Duct for Outside Air
 | UD4
Compatible with the following Monessen appliances
|
You Can Also Buy Available Mantel Shelf with This Product
You Can Also Buy Available Shelf Corbels with This Product
You Can Also Buy Available Marble, Granite & Slate with This Product
